queso-0.51.1
|
Class for handling vector samples (sequence of vectors). More...
#include <SequenceOfVectors.h>
Public Types | |
Class typedefs | |
typedef std::vector< const V * > ::const_iterator | seqVectorPositionConstIteratorTypedef |
typedef std::vector< const V * > ::iterator | seqVectorPositionIteratorTypedef |
Public Member Functions | |
Constructor/Destructor methods | |
SequenceOfVectors (const VectorSpace< V, M > &vectorSpace, unsigned int subSequenceSize, const std::string &name) | |
Default constructor. More... | |
~SequenceOfVectors () | |
Destructor. More... | |
Set methods | |
SequenceOfVectors< V, M > & | operator= (const SequenceOfVectors< V, M > &rhs) |
Copies values from rhs to this . More... | |
Sequence methods | |
unsigned int | subSequenceSize () const |
Size of the sub-sequence of vectors. More... | |
void | resizeSequence (unsigned int newSubSequenceSize) |
Resizes the sequence. More... | |
void | resetValues (unsigned int initialPos, unsigned int numPos) |
Resets a total of numPos values of the sequence starting at position initialPos . More... | |
void | erasePositions (unsigned int initialPos, unsigned int numPos) |
Erases numPos elements of the sequence starting at position initialPos . More... | |
void | getPositionValues (unsigned int posId, V &vec) const |
Gets the values of the sequence at position posId and stores them at vec . More... | |
void | setPositionValues (unsigned int posId, const V &vec) |
Set the values in vec at position posId of the sequence. More... | |
void | subUniformlySampledCdf (const V &numEvaluationPointsVec, ArrayOfOneDGrids< V, M > &cdfGrids, ArrayOfOneDTables< V, M > &cdfValues) const |
Uniformly samples from the CDF from the sub-sequence. More... | |
void | unifiedUniformlySampledCdf (const V &numEvaluationPointsVec, ArrayOfOneDGrids< V, M > &unifiedCdfGrids, ArrayOfOneDTables< V, M > &unifiedCdfValues) const |
Uniformly samples from the CDF from the sub-sequence. More... | |
void | subMeanExtra (unsigned int initialPos, unsigned int numPos, V &meanVec) const |
Finds the mean value of the sub-sequence, considering numPos positions starting at position initialPos . More... | |
void | unifiedMeanExtra (unsigned int initialPos, unsigned int numPos, V &unifiedMeanVec) const |
Finds the mean value of the unified sequence, considering numPos positions starting at position initialPos . More... | |
void | subMedianExtra (unsigned int initialPos, unsigned int numPos, V &medianVec) const |
Finds the median value of the sub-sequence, considering numPos positions starting at position initialPos . More... | |
void | unifiedMedianExtra (unsigned int initialPos, unsigned int numPos, V &unifiedMedianVec) const |
Finds the median value of the unfed sequence, considering numPos positions starting at position initialPos . More... | |
void | subSampleVarianceExtra (unsigned int initialPos, unsigned int numPos, const V &meanVec, V &samVec) const |
Finds the sample variance of the sub-sequence, considering numPos positions starting at position initialPos and of mean meanVec . More... | |
void | unifiedSampleVarianceExtra (unsigned int initialPos, unsigned int numPos, const V &unifiedMeanVec, V &unifiedSamVec) const |
Finds the sample variance of the unified sequence, considering numPos positions starting at position initialPos and of mean meanVec . More... | |
void | subSampleStd (unsigned int initialPos, unsigned int numPos, const V &meanVec, V &stdVec) const |
Finds the sample standard deviation of the sub-sequence, considering numPos positions starting at position initialPos and of mean meanVec . More... | |
void | unifiedSampleStd (unsigned int initialPos, unsigned int numPos, const V &unifiedMeanVec, V &unifiedStdVec) const |
Finds the sample standard deviation of the unified sequence, considering numPos positions starting at position initialPos and of mean meanVec . More... | |
void | subPopulationVariance (unsigned int initialPos, unsigned int numPos, const V &meanVec, V &popVec) const |
Finds the population variance of the sub-sequence, considering numPos positions starting at position initialPos and of mean meanVec . More... | |
void | unifiedPopulationVariance (unsigned int initialPos, unsigned int numPos, const V &unifiedMeanVec, V &unifiedPopVec) const |
Finds the population variance of the unified sequence, considering numPos positions starting at position initialPos and of mean meanVec . More... | |
void | autoCovariance (unsigned int initialPos, unsigned int numPos, const V &meanVec, unsigned int lag, V &covVec) const |
Calculates the autocovariance. More... | |
void | autoCorrViaDef (unsigned int initialPos, unsigned int numPos, unsigned int lag, V &corrVec) const |
Calculates the autocorrelation via definition. More... | |
void | autoCorrViaFft (unsigned int initialPos, unsigned int numPos, const std::vector< unsigned int > &lags, std::vector< V * > &corrVecs) const |
Calculates the autocorrelation via Fast Fourier transforms (FFT). More... | |
void | autoCorrViaFft (unsigned int initialPos, unsigned int numPos, unsigned int numSum, V &autoCorrsSumVec) const |
Calculates the autocorrelation via Fast Fourier transforms (FFT). More... | |
void | subMinMaxExtra (unsigned int initialPos, unsigned int numPos, V &minVec, V &maxVec) const |
Finds the minimum and the maximum values of the sub-sequence, considering numPos positions starting at position initialPos . More... | |
void | unifiedMinMaxExtra (unsigned int initialPos, unsigned int numPos, V &unifiedMinVec, V &unifiedMaxVec) const |
Finds the minimum and the maximum values of the unified sequence, considering numPos positions starting at position initialPos . More... | |
void | subHistogram (unsigned int initialPos, const V &minVec, const V &maxVec, std::vector< V * > ¢ersForAllBins, std::vector< V * > &quanttsForAllBins) const |
Calculates the histogram of the sub-sequence. More... | |
void | unifiedHistogram (unsigned int initialPos, const V &unifiedMinVec, const V &unifiedMaxVec, std::vector< V * > &unifiedCentersForAllBins, std::vector< V * > &unifiedQuanttsForAllBins) const |
Calculates the histogram of the unified sequence. More... | |
void | subInterQuantileRange (unsigned int initialPos, V &iqrVec) const |
Returns the interquartile range of the values in the sub-sequence. More... | |
void | unifiedInterQuantileRange (unsigned int initialPos, V &unifiedIqrVec) const |
Returns the interquartile range of the values in the unified sequence. More... | |
void | subScalesForKde (unsigned int initialPos, const V &iqrVec, unsigned int kdeDimension, V &scaleVec) const |
Selects the scales (bandwidth, scaleVec ) for the kernel density estimation, considering only the sub-sequence. More... | |
void | unifiedScalesForKde (unsigned int initialPos, const V &unifiedIqrVec, unsigned int kdeDimension, V &unifiedScaleVec) const |
Selects the scales (bandwidth) for the kernel density estimation, considering the unified sequence. More... | |
void | subGaussian1dKde (unsigned int initialPos, const V &scaleVec, const std::vector< V * > &evalParamVecs, std::vector< V * > &densityVecs) const |
Gaussian kernel for the KDE estimate of the sub-sequence. More... | |
void | unifiedGaussian1dKde (unsigned int initialPos, const V &unifiedScaleVec, const std::vector< V * > &unifiedEvalParamVecs, std::vector< V * > &unifiedDensityVecs) const |
Gaussian kernel for the KDE estimate of the unified sequence. More... | |
void | subWriteContents (unsigned int initialPos, unsigned int numPos, const std::string &fileName, const std::string &fileType, const std::set< unsigned int > &allowedSubEnvIds) const |
Writes the sub-sequence to a file. More... | |
void | subWriteContents (unsigned int initialPos, unsigned int numPos, FilePtrSetStruct &filePtrSet, const std::string &fileType) const |
Writes the sub-sequence to a file. More... | |
void | subWriteContents (unsigned int initialPos, unsigned int numPos, std::ofstream &ofs, const std::string &fileType) const |
Writes the sub-sequence to a file. More... | |
void | unifiedWriteContents (const std::string &fileName, const std::string &fileType) const |
void | unifiedReadContents (const std::string &fileName, const std::string &fileType, const unsigned int subSequenceSize) |
Reads the unified sequence from a file. More... | |
void | select (const std::vector< unsigned int > &idsOfUniquePositions) |
TODO: It shall select positions in the sequence of vectors. More... | |
void | filter (unsigned int initialPos, unsigned int spacing) |
Filters positions in the sequence of vectors. More... | |
double | estimateConvBrooksGelman (unsigned int initialPos, unsigned int numPos) const |
Estimates convergence rate using Brooks & Gelman method. More... | |
void | extractScalarSeq (unsigned int initialPos, unsigned int spacing, unsigned int numPos, unsigned int paramId, ScalarSequence< double > &scalarSeq) const |
Extracts a sequence of scalars. More... | |
Public Member Functions inherited from QUESO::BaseVectorSequence< V, M > | |
BaseVectorSequence (const VectorSpace< V, M > &vectorSpace, unsigned int subSequenceSize, const std::string &name) | |
Default constructor. More... | |
virtual | ~BaseVectorSequence () |
Destructor. More... | |
unsigned int | unifiedSequenceSize () const |
Calculates the size of the unified sequence of vectors. More... | |
unsigned int | vectorSizeLocal () const |
Local dimension (size) of the vector space. More... | |
unsigned int | vectorSizeGlobal () const |
Global dimension (size) of the vector space. More... | |
const VectorSpace< V, M > & | vectorSpace () const |
Vector space; access to protected attribute VectorSpace<V,M>& m_vectorSpace. More... | |
const std::string & | name () const |
Access to protected attribute m_name: name of the sequence of vectors. More... | |
void | setName (const std::string &newName) |
Changes the name of the sequence of vectors. More... | |
void | clear () |
Reset the values and the size of the sequence of vectors. More... | |
const V & | subMinPlain () const |
Finds the minimum value of the sub-sequence. More... | |
const V & | unifiedMinPlain () const |
Finds the minimum value of the unified sequence. More... | |
const V & | subMaxPlain () const |
Finds the maximum value of the sub-sequence. More... | |
const V & | unifiedMaxPlain () const |
Finds the maximum value of the unified sequence. More... | |
const V & | subMeanPlain () const |
Finds the mean value of the sub-sequence. More... | |
const V & | unifiedMeanPlain () const |
Finds the mean value of the unified sequence. More... | |
const V & | subMedianPlain () const |
Finds the median value of the sub-sequence. More... | |
const V & | unifiedMedianPlain () const |
Finds the median value of the unified sequence. More... | |
const V & | subSampleVariancePlain () const |
Finds the variance of a sample of the sub-sequence. More... | |
const V & | unifiedSampleVariancePlain () const |
Finds the variance of a sample of the unified sequence. More... | |
const BoxSubset< V, M > & | subBoxPlain () const |
Finds a box subset of the sub-sequence (given by its min and max values calculated via subMinPlain and subMaxPlain). More... | |
const BoxSubset< V, M > & | unifiedBoxPlain () const |
Finds a box subset of the unified-sequence (given by the min and max values of the unified sequence calculated via unifiedMinPlain and unifiedMaxPlain). More... | |
void | deleteStoredVectors () |
Deletes all the stored vectors. More... | |
void | append (const BaseVectorSequence< V, M > &src, unsigned int initialPos, unsigned int numPos) |
Appends the vector src to this vector. More... | |
double | subPositionsOfMaximum (const ScalarSequence< double > &subCorrespondingScalarValues, BaseVectorSequence< V, M > &subPositionsOfMaximum) |
Finds the positions where the maximum element occurs in the sub-sequence. More... | |
double | unifiedPositionsOfMaximum (const ScalarSequence< double > &subCorrespondingScalarValues, BaseVectorSequence< V, M > &unifiedPositionsOfMaximum) |
Finds the positions where the maximum element occurs in the unified sequence. More... | |
void | setGaussian (const V &meanVec, const V &stdDevVec) |
Sets the values of the sequence as a Gaussian distribution of mean given by meanVec and standard deviation by stdDevVec . More... | |
void | setUniform (const V &aVec, const V &bVec) |
Sets the values of the sequence as a uniform distribution between the values given by vectors aVec and bVec . More... | |
void | computeFilterParams (std::ofstream *passedOfs, unsigned int &initialPos, unsigned int &spacing) |
Computes the filtering parameters spacing for the sequence of vectors. More... | |
Private Member Functions | |
void | copy (const SequenceOfVectors< V, M > &src) |
Copies vector sequence src to this . More... | |
void | extractRawData (unsigned int initialPos, unsigned int spacing, unsigned int numPos, unsigned int paramId, std::vector< double > &rawData) const |
Extracts the raw data. More... | |
Private Attributes | |
std::vector< const V * > | m_seq |
Sequence of vectors. More... | |
Additional Inherited Members | |
Protected Member Functions inherited from QUESO::BaseVectorSequence< V, M > | |
void | copy (const BaseVectorSequence< V, M > &src) |
Copies vector sequence src to this . More... | |
Protected Attributes inherited from QUESO::BaseVectorSequence< V, M > | |
const BaseEnvironment & | m_env |
const VectorSpace< V, M > & | m_vectorSpace |
std::string | m_name |
Fft< double > * | m_fftObj |
V * | m_subMinPlain |
V * | m_unifiedMinPlain |
V * | m_subMaxPlain |
V * | m_unifiedMaxPlain |
V * | m_subMeanPlain |
V * | m_unifiedMeanPlain |
V * | m_subMedianPlain |
V * | m_unifiedMedianPlain |
V * | m_subSampleVariancePlain |
V * | m_unifiedSampleVariancePlain |
BoxSubset< V, M > * | m_subBoxPlain |
BoxSubset< V, M > * | m_unifiedBoxPlain |
Class for handling vector samples (sequence of vectors).
This class handles vector samples generated by an algorithm, as well as operations that can be carried over them, e.g., calculation of means, correlation and covariance matrices. It is derived from and implements BaseVectorSequence<V,M>.
Definition at line 46 of file SequenceOfVectors.h.
typedef std::vector<const V*>::const_iterator QUESO::SequenceOfVectors< V, M >::seqVectorPositionConstIteratorTypedef |
Definition at line 52 of file SequenceOfVectors.h.
typedef std::vector<const V*>::iterator QUESO::SequenceOfVectors< V, M >::seqVectorPositionIteratorTypedef |
Definition at line 53 of file SequenceOfVectors.h.
QUESO::SequenceOfVectors< V, M >::SequenceOfVectors | ( | const VectorSpace< V, M > & | vectorSpace, |
unsigned int | subSequenceSize, | ||
const std::string & | name | ||
) |
Default constructor.
Definition at line 33 of file SequenceOfVectors.C.
QUESO::SequenceOfVectors< V, M >::~SequenceOfVectors | ( | ) |
Destructor.
Definition at line 68 of file SequenceOfVectors.C.
|
virtual |
Calculates the autocorrelation via definition.
Autocorrelation is the cross-correlation of a variable with itself; it describes the correlation between values of the process at different times, as a function of the two times. It is calculated over a sequence of vectors with initial position initialPos
, considering numPos
positions, a lag of lag
, with mean given by meanVec
. Output:
corrVec | is the vector of the calculated autocorrelations of the sequence of vectors. |
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 820 of file SequenceOfVectors.C.
References UQ_FATAL_TEST_MACRO.
|
virtual |
Calculates the autocorrelation via Fast Fourier transforms (FFT).
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 855 of file SequenceOfVectors.C.
References QUESO::ScalarSequence< T >::autoCorrViaFft(), and UQ_FATAL_TEST_MACRO.
|
virtual |
Calculates the autocorrelation via Fast Fourier transforms (FFT).
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 917 of file SequenceOfVectors.C.
References UQ_FATAL_TEST_MACRO.
|
virtual |
Calculates the autocovariance.
The autocovariance is the covariance of a variable with itself at some other time. It is calculated over a sequence of vectors with initial position initialPos
, considering numPos
positions, a lag of lag
, with mean given by meanVec
. Output:
covVec | is the vector of the calculated autocovariances of the sequence of vectors. |
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 782 of file SequenceOfVectors.C.
References UQ_FATAL_TEST_MACRO.
|
private |
Copies vector sequence src
to this
.
Definition at line 2274 of file SequenceOfVectors.C.
References QUESO::BaseVectorSequence< V, M >::copy(), QUESO::SequenceOfVectors< V, M >::m_seq, and QUESO::SequenceOfVectors< V, M >::subSequenceSize().
|
virtual |
Erases numPos
elements of the sequence starting at position initialPos
.
This routine deletes all stored computed vectors
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 157 of file SequenceOfVectors.C.
References QUESO::BaseVectorSequence< V, M >::deleteStoredVectors(), and UQ_FATAL_TEST_MACRO.
|
virtual |
Estimates convergence rate using Brooks & Gelman method.
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 2120 of file SequenceOfVectors.C.
References QUESO::matrixProduct(), and UQ_FATAL_RC_MACRO.
|
privatevirtual |
Extracts the raw data.
This method saves in rawData
the data from the sequence of vectors (in private attribute m_seq
) starting at position (initialPos
,paramId
) , with a spacing of spacing
until numPos
positions have been extracted.
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 2293 of file SequenceOfVectors.C.
|
virtual |
Extracts a sequence of scalars.
The sequence of scalars has size numPos
, and it will be extracted starting at position (initialPos
, paramId
) of this
sequences of vectors, given spacing spacing
.
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 2250 of file SequenceOfVectors.C.
References QUESO::ScalarSequence< T >::resizeSequence().
|
virtual |
Filters positions in the sequence of vectors.
Filtered positions will starting at initialPos
, and with spacing given by spacing
.
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 2079 of file SequenceOfVectors.C.
Referenced by QUESO::MLSampling< P_V, P_M >::generateSequence(), and QUESO::MLSampling< P_V, P_M >::generateSequence_Step11_inter0().
|
virtual |
Gets the values of the sequence at position posId
and stores them at vec
.
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 197 of file SequenceOfVectors.C.
References UQ_FATAL_TEST_MACRO.
Referenced by QUESO::MLSampling< P_V, P_M >::generateBalLinkedChains_all(), QUESO::MLSampling< P_V, P_M >::generateSequence(), QUESO::MetropolisHastingsSG< P_V, P_M >::generateSequence(), QUESO::MLSampling< P_V, P_M >::generateSequence_Step02_inter0(), QUESO::MLSampling< P_V, P_M >::generateSequence_Step04_inter0(), QUESO::MLSampling< P_V, P_M >::generateUnbLinkedChains_all(), and QUESO::MLSampling< P_V, P_M >::mpiExchangePositions_inter0().
SequenceOfVectors< V, M > & QUESO::SequenceOfVectors< V, M >::operator= | ( | const SequenceOfVectors< V, M > & | rhs | ) |
Copies values from rhs
to this
.
Definition at line 94 of file SequenceOfVectors.C.
|
virtual |
Resets a total of numPos
values of the sequence starting at position initialPos
.
This routine deletes all stored computed vectors
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 126 of file SequenceOfVectors.C.
References QUESO::BaseVectorSequence< V, M >::deleteStoredVectors(), and UQ_FATAL_TEST_MACRO.
|
virtual |
Resizes the sequence.
This routine deletes all stored computed vectors
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 110 of file SequenceOfVectors.C.
References QUESO::BaseVectorSequence< V, M >::deleteStoredVectors().
Referenced by QUESO::MetropolisHastingsSG< P_V, P_M >::generateFullChain(), and QUESO::MLSampling< P_V, P_M >::generateSequence_Level0_all().
|
virtual |
TODO: It shall select positions in the sequence of vectors.
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 2065 of file SequenceOfVectors.C.
References UQ_FATAL_RC_MACRO.
|
virtual |
Set the values in vec
at position posId
of the sequence.
This routine deletes all stored computed vectors
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 221 of file SequenceOfVectors.C.
References QUESO::BaseVectorSequence< V, M >::deleteStoredVectors(), and UQ_FATAL_TEST_MACRO.
Referenced by QUESO::MetropolisHastingsSG< P_V, P_M >::generateFullChain(), and QUESO::MLSampling< P_V, P_M >::generateSequence_Level0_all().
|
virtual |
Gaussian kernel for the KDE estimate of the sub-sequence.
Computes a probability density estimate of the sample in this
sub-sequence, starting at position initialPos
. densityVecs
is the vector of density values evaluated at the points in evaluationParamVecs
. The estimate is based on Gaussian (normal) kernel function, using a window parameter (scaleVec
).
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 1252 of file SequenceOfVectors.C.
References QUESO::ScalarSequence< T >::subGaussian1dKde(), and UQ_FATAL_TEST_MACRO.
|
virtual |
Calculates the histogram of the sub-sequence.
It requires the specification of the number of bins that the histogram will have, the center of each bin and the initial position where the data will be considered.
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 1025 of file SequenceOfVectors.C.
References QUESO::ScalarSequence< T >::subHistogram(), and UQ_FATAL_TEST_MACRO.
|
virtual |
Returns the interquartile range of the values in the sub-sequence.
The IQR is a robust estimate of the spread of the data, since changes in the upper and lower 25% of the data do not affect it. If there are outliers in the data, then the IQR is more representative than the standard deviation as an estimate of the spread of the body of the data. The IQR is less efficient than the standard deviation as an estimate of the spread when the data is all from the normal distribution. (from Matlab)
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 1124 of file SequenceOfVectors.C.
References QUESO::ScalarSequence< T >::subInterQuantileRange(), and UQ_FATAL_TEST_MACRO.
|
virtual |
Finds the mean value of the sub-sequence, considering numPos
positions starting at position initialPos
.
Output:
meanVec | is the vector of the calculated means of the sub-sequence of vectors. |
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 329 of file SequenceOfVectors.C.
References UQ_FATAL_TEST_MACRO.
|
virtual |
Finds the median value of the sub-sequence, considering numPos
positions starting at position initialPos
.
Output:
medianVec | is the vector of the calculated medians of the sub-sequence of vectors. |
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 449 of file SequenceOfVectors.C.
References UQ_FATAL_TEST_MACRO.
|
virtual |
Finds the minimum and the maximum values of the sub-sequence, considering numPos
positions starting at position initialPos
.
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 955 of file SequenceOfVectors.C.
References QUESO::ScalarSequence< T >::subMinMaxExtra(), and UQ_FATAL_TEST_MACRO.
|
virtual |
Finds the population variance of the sub-sequence, considering numPos
positions starting at position initialPos
and of mean meanVec
.
Output:
popVec | is the vector of the calculated population variance of the sub-sequence of vectors. The population variance is defined by , where is the sample mean and is the sample size. This procedure lets the users choose the initial position and the number of elements of the sequence which will be used to evaluate the population variance . |
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 711 of file SequenceOfVectors.C.
References UQ_FATAL_TEST_MACRO.
void QUESO::SequenceOfVectors< V, M >::subSampleStd | ( | unsigned int | initialPos, |
unsigned int | numPos, | ||
const V & | meanVec, | ||
V & | stdVec | ||
) | const |
Finds the sample standard deviation of the sub-sequence, considering numPos
positions starting at position initialPos
and of mean meanVec
.
Output:
stdVec | is the vector of the calculated sample standard deviation of the sub-sequence of vectors. |
Definition at line 640 of file SequenceOfVectors.C.
References UQ_FATAL_TEST_MACRO.
|
virtual |
Finds the sample variance of the sub-sequence, considering numPos
positions starting at position initialPos
and of mean meanVec
.
Output:
samVec | is the vector of the calculated sample variance of the sub-sequence of vectors. The sample variance is the second sample central moment and is defined by , where is the sample mean and is the sample size. This procedure lets the users choose the initial position and the number of elements of the sequence which will be used to evaluate the sample variance. |
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 569 of file SequenceOfVectors.C.
References UQ_FATAL_TEST_MACRO.
|
virtual |
Selects the scales (bandwidth, scaleVec
) for the kernel density estimation, considering only the sub-sequence.
The bandwidth of the kernel is a free parameter which exhibits a strong influence on the resulting estimate. Silverman (1986) suggests the following normal-based estimates: S1 = 1.06 × (standard deviation) × n^{-1/5} S2 = 0.79 × (iqrVec
) × n^{-1/5}, where iqrVec
is the interquartile range scaleVec
= 0.90 × minimum(standard deviation, iqrVec
/1.34) × n^{-1/5}. These estimates are popular due to their simplicity, and are used in QUESO with the adaptation of the exponent oven the sample size n (-1/5) with -1/(4 + kdeDimension
) where kdeDimension
is the KDE dimension.
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 1183 of file SequenceOfVectors.C.
References QUESO::ScalarSequence< T >::subScaleForKde(), and UQ_FATAL_TEST_MACRO.
|
virtual |
Size of the sub-sequence of vectors.
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 103 of file SequenceOfVectors.C.
Referenced by QUESO::SequenceOfVectors< V, M >::copy(), QUESO::MLSampling< P_V, P_M >::generateBalLinkedChains_all(), QUESO::MetropolisHastingsSG< P_V, P_M >::generateFullChain(), QUESO::MLSampling< P_V, P_M >::generateSequence(), QUESO::MetropolisHastingsSG< P_V, P_M >::generateSequence(), QUESO::MLSampling< P_V, P_M >::generateSequence_Level0_all(), QUESO::MLSampling< P_V, P_M >::generateSequence_Step02_inter0(), QUESO::MLSampling< P_V, P_M >::generateSequence_Step11_inter0(), and QUESO::MLSampling< P_V, P_M >::generateUnbLinkedChains_all().
void QUESO::SequenceOfVectors< V, M >::subUniformlySampledCdf | ( | const V & | numEvaluationPointsVec, |
ArrayOfOneDGrids< V, M > & | cdfGrids, | ||
ArrayOfOneDTables< V, M > & | cdfValues | ||
) | const |
Uniformly samples from the CDF from the sub-sequence.
Definition at line 248 of file SequenceOfVectors.C.
References QUESO::ArrayOfOneDTables< V, M >::setOneDTable(), and QUESO::ArrayOfOneDGrids< V, M >::setUniformGrids().
Referenced by QUESO::StatisticalForwardProblem< P_V, P_M, Q_V, Q_M >::solveWithMonteCarlo().
|
virtual |
Writes the sub-sequence to a file.
Given the allowed sub environments (allowedSubEnvIds
) that are allowed to write to file, together with the file name and type (fileName
, fileType
), it writes the entire sub- sequence to the file. The sum of the initial position of the sequence (initialPos
) with the number of positions that will be written (numPos
) must equal the size of the sequence. This procedure calls void subWriteContents (unsigned int initialPos, unsigned int numPos, FilePtrSetStruct& filePtrSet, const std::string& fileType).
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 1357 of file SequenceOfVectors.C.
References UQ_FATAL_TEST_MACRO.
void QUESO::SequenceOfVectors< V, M >::subWriteContents | ( | unsigned int | initialPos, |
unsigned int | numPos, | ||
FilePtrSetStruct & | filePtrSet, | ||
const std::string & | fileType | ||
) | const |
Writes the sub-sequence to a file.
Uses additional variable of the type FilePtrSetStruct& to operate on files.
Definition at line 1408 of file SequenceOfVectors.C.
References UQ_FATAL_TEST_MACRO, UQ_FILE_EXTENSION_FOR_HDF_FORMAT, and UQ_FILE_EXTENSION_FOR_MATLAB_FORMAT.
|
virtual |
Writes the sub-sequence to a file.
Uses object of the type std::ofstream.
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 1443 of file SequenceOfVectors.C.
References UQ_FATAL_TEST_MACRO.
|
virtual |
Gaussian kernel for the KDE estimate of the unified sequence.
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 1304 of file SequenceOfVectors.C.
References QUESO::ScalarSequence< T >::unifiedGaussian1dKde(), and UQ_FATAL_TEST_MACRO.
|
virtual |
Calculates the histogram of the unified sequence.
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 1074 of file SequenceOfVectors.C.
References QUESO::ScalarSequence< T >::unifiedHistogram(), and UQ_FATAL_TEST_MACRO.
|
virtual |
Returns the interquartile range of the values in the unified sequence.
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 1153 of file SequenceOfVectors.C.
References QUESO::ScalarSequence< T >::unifiedInterQuantileRange(), and UQ_FATAL_TEST_MACRO.
|
virtual |
Finds the mean value of the unified sequence, considering numPos
positions starting at position initialPos
.
Output:
meanVec | is the vector of the calculated means of the unified sequence of vectors. |
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 387 of file SequenceOfVectors.C.
References UQ_FATAL_TEST_MACRO.
|
virtual |
Finds the median value of the unfed sequence, considering numPos
positions starting at position initialPos
.
Output:
medianVec | is the vector of the calculated medians of the unified sequence of vectors. |
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 507 of file SequenceOfVectors.C.
References UQ_FATAL_TEST_MACRO.
|
virtual |
Finds the minimum and the maximum values of the unified sequence, considering numPos
positions starting at position initialPos
.
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 988 of file SequenceOfVectors.C.
References QUESO::ScalarSequence< T >::unifiedMinMaxExtra(), and UQ_FATAL_TEST_MACRO.
|
virtual |
Finds the population variance of the unified sequence, considering numPos
positions starting at position initialPos
and of mean meanVec
.
Output:
popVec | is the vector of the calculated population variance of the unified sequence of vectors. |
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 746 of file SequenceOfVectors.C.
References UQ_FATAL_TEST_MACRO.
|
virtual |
Reads the unified sequence from a file.
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 1760 of file SequenceOfVectors.C.
References QUESO::FilePtrSetStruct::ifsVar, QUESO::MiscGetEllapsedSeconds(), UQ_FATAL_TEST_MACRO, UQ_FILE_EXTENSION_FOR_HDF_FORMAT, UQ_FILE_EXTENSION_FOR_MATLAB_FORMAT, and QUESO::UQ_OK_RC.
Referenced by QUESO::MLSampling< P_V, P_M >::restartML().
void QUESO::SequenceOfVectors< V, M >::unifiedSampleStd | ( | unsigned int | initialPos, |
unsigned int | numPos, | ||
const V & | unifiedMeanVec, | ||
V & | unifiedStdVec | ||
) | const |
Finds the sample standard deviation of the unified sequence, considering numPos
positions starting at position initialPos
and of mean meanVec
.
Output:
stdVec | is the vector of the calculated sample standard deviation of the unified sequence of vectors. |
Definition at line 675 of file SequenceOfVectors.C.
References UQ_FATAL_TEST_MACRO.
|
virtual |
Finds the sample variance of the unified sequence, considering numPos
positions starting at position initialPos
and of mean meanVec
.
Output:
samVec | is the vector of the calculated sample variance of the unified sequence of vectors. |
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 604 of file SequenceOfVectors.C.
References UQ_FATAL_TEST_MACRO.
|
virtual |
Selects the scales (bandwidth) for the kernel density estimation, considering the unified sequence.
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 1217 of file SequenceOfVectors.C.
References QUESO::ScalarSequence< T >::unifiedScaleForKde(), and UQ_FATAL_TEST_MACRO.
void QUESO::SequenceOfVectors< V, M >::unifiedUniformlySampledCdf | ( | const V & | numEvaluationPointsVec, |
ArrayOfOneDGrids< V, M > & | unifiedCdfGrids, | ||
ArrayOfOneDTables< V, M > & | unifiedCdfValues | ||
) | const |
Uniformly samples from the CDF from the sub-sequence.
Definition at line 283 of file SequenceOfVectors.C.
References QUESO::ArrayOfOneDTables< V, M >::setOneDTable(), and QUESO::ArrayOfOneDGrids< V, M >::setUniformGrids().
Referenced by QUESO::StatisticalForwardProblem< P_V, P_M, Q_V, Q_M >::solveWithMonteCarlo().
|
virtual |
Writes the unfed sequence to a file. Writes the unified sequence in Matlab/Octave format or, if enabled, in HDF5 format.
Implements QUESO::BaseVectorSequence< V, M >.
Definition at line 1485 of file SequenceOfVectors.C.
References QUESO::MiscGetEllapsedSeconds(), QUESO::FilePtrSetStruct::ofsVar, UQ_FATAL_TEST_MACRO, UQ_FILE_EXTENSION_FOR_HDF_FORMAT, UQ_FILE_EXTENSION_FOR_MATLAB_FORMAT, and QUESO::UQ_OK_RC.
Referenced by QUESO::MLSampling< P_V, P_M >::checkpointML(), QUESO::MLSampling< P_V, P_M >::generateSequence(), QUESO::MLSampling< P_V, P_M >::generateSequence_Level0_all(), and QUESO::MLSampling< P_V, P_M >::generateSequence_Step11_inter0().
|
private |
Sequence of vectors.
Definition at line 417 of file SequenceOfVectors.h.
Referenced by QUESO::SequenceOfVectors< V, M >::copy().
